OPTICAL SYSTEM
Light Source: 1000W white light LED module
Optical lens: φ175mm diameter with optics coating technology
Zoom Range: 5° - 50°
High CRI mode: Ra≥90
COLOR SYSTEM
CMY infinite color mixing
CTO linear adjustment
6 color filters + white light, can realize bidirectional color rainbow effect, double-colors stepping gradually (linear movement), color wheel bidirectional rotation, color change at random
GOBO SYSTEM
1 rotating gobo wheels with 6 glass gobos, in bidirectional rotation way
1 fixed gobo wheel with 9 gobos
1 animation gobo wheel, can fade in / out
FRAMING SYSTEM
1 set of full directional framing system, support 90° rotation
Framing blade position with high precision
EFFECT EQUIPMENT
1 rotating 4-facet prism gradient prism
1 rotating 4-facet prism prism
2 independent soft light frost effect, overlap with each other
Fast electronic iris, 5-100 % linear adjustment, macro function and multi effect change
CONTROL AND PROGRAMMING
Control channel: 32(standard)/ 36(16 bit)/ 43(extended) 3 channel modes
Protocol: Standard DMX512, Art-net Ethernet Control Protocol, Optional: wireless DMX512
DIMENSION AND WEIGHT
414mm×310mm×788mm
Net Weight: 33.5 kg (fixture)
